| Camera |
| Image Sensor |
1/4 type interline transfer CCD |
| Effective Pixels |
NTSC: 976(H)x494(V)
PAL: 976(H)x582(V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
3.6(H)x2.7(V) mm |
| Horizontal Resolution |
650 TV line typical |
| Minimum Illumination |
Color 0.5 lx (50 IRE, F1.4, Shutter:NTSC 1/60 sec, PAL 1/50 sec, Gain:High, Sense UP:OFF)
B/W 0.04 lx (50 IRE, F1.4, Shutter:NTSC 1/60 sec, PAL 1/50 sec, Gain:High, Sense UP:OFF) |
| Video S/N Ratio |
More than 50 dB (AGC: OFF) |
| Backlight compensation |
Multi / Center / OFF (Mask settings possible) |
| White Balance |
AWC / ATW / MWB (Adjustable R and B signals) / Outdoor / Indoor / Fluorescent |
| Iris Conrtrol |
Auto / Manual |
| AGC |
Low / Middle / High / OFF (Adjustable) |
| Super Dynamic |
ON / OFF (ON: 54 dB typical) |
| Electronic Shutter |
NTSC:1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10 000 sec.
PAL :1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10 000 sec.
Long shutter : x1, x2, x4, x6, x10, x16, x32, x64, x128, x256, x512 |
| Electronic Sensitivity UP |
Auto / OFF, max 32x |
| Electronic iris |
ON / OFF |
| Day & Night (IR) |
Auto / Color / BW |
| Digital Noise Reduction |
High / Low |
| Gamma |
0.45 / 1 / SMART1 / SMART2 |
| Video Motion Detection |
ON / OFF, adjustable sensitivities |
| Privacy Mask |
ON / OFF, up to 8 zones |
| Mirror Image Effect |
H/V / HV / OFF |
| Image Stabilizer |
ON / OFF |
| Camera Title (OSD |
16 alphanumeric characters (cameraID:8 + Title:8) |
| Auto Focus |
Auto / Manual / One-Push / Stop AF |
| Aperture compensation |
ON / OFF (H/V settings possible) |
| Synchronization |
Internal / External (V-sync.) |
| Lens |
| Focal Length |
3.3 mm ~ 79.2 mm / F1.4-2.8 |
| Zoom Ratio |
24x Optical Zoom, 20x Ditgital Zoom |
| View Angle |
Horizontal : 2.7°~ 60.2°
Vertical : 2.0°~ 46.0°
Diagonal : 3.4°~ 72.8° |
| Input/Output |
| Video Output |
NTSC: Composite, 1.0 Vp-p, 75 Ω
PAL : Composite, 1.0 Vp-p, 75 Ω |
| Communication Interface |
UART (CMOS Level) |
| General |
| Power supply |
6-12 V DC (Recommendation : DC9 V) |
| Power Consumption (approx.) |
2.4 W (3.4 W, motor active) |
| Ambient Operating Temperature |
–10℃ ~ +50°C (14°F ~ 122°F) |
| Ambient Storage Temperature |
–20°C ~ +70°C (-4°F ~ 158°F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions (approx.) |
50 mm (W) x 60 mm (H) x 89 mm (L) ( 2" (W) x 2-3/8" (H) x 3-1/2" (L) ) |
| Weight (approx.) |
260 g (9.17 oz) |
