| Camera |
| Image Sensor |
1/2.8-type Exmor CMOS |
| Number of Effective Pixels |
Approx. 3.27 Megapixels |
| Signal System |
NTSC color system/PAL color system (switchable) |
| Sync System |
Internal synchronization |
| Minimum Illumination (50 IRE) |
Color: 0.40 lx (F1.2, View-DR OFF, VE OFF, AGC High, XDNR Mid, 50 IRE)
B/W: 0 lx (F1.2, View-DR OFF, VE OFF, AGC High, XDNR Mid, 50 IRE) |
| Minimum Illumination (30 IRE) |
Color: 0.25 lx (F1.2, View-DR OFF, VE OFF, AGC High, XDNR Mid, 30 IRE)
B/W: 0. lx (F1.2, View-DR OFF, VE OFF, AGC High, XDNR Mid, 30 IRE) |
| Dynamic Range |
Equivalent 90 dB by View-DR Technology |
| S/N Ratio (Gain 0 dB) |
More than 50 dB (AGC 0 dB) |
| Gain |
Auto (3 levels) |
| Shutter Speed |
1/1 s to 1/10000 s |
| Exposure Control |
Exposure compensation, AGC, Shutter speed |
| White Balance |
ATW, ATW-PRO, Fluorescent lamp, Mercury lamp, Sodium vapour lamp, Metal halide lamp, White LED, One push WB, Manual |
| Lens |
Built-in varifocal lens |
| Powered Zoom |
No |
| Easy Zoom |
Yes |
| Zoom Ratio |
Optical zoom 2.9x
Digital zoom 4x
Total zoom 11.6x |
| Powered Focus |
Yes |
| Horizontal Viewing Angle |
88.5° to 32.3° |
| Vertical Viewing Angle |
65.2° to 24.2° |
| Focal Length |
f = 3.1 mm to 8.9 mm |
| F-Number |
F1.2 to F2.1 |
| Minimum Object Distance |
300 mm |
| IR Illuminator |
Yes (Wave Length: 850 nm [Typical], IR LED: 21 pieces) |
| IR Working Distance |
30 m (50 IRE) |
| Camera Features |
| Day/Night |
True D/N |
| Wide-D |
View-DR |
| Tone Correction |
VE (VE) |
| Noise Reduction |
XDNR |
| Image Stabilizer |
No |
| Vandal Resistant |
IK10 |
| Ingress Protection |
IP66 |
| Video |
| Resolution |
1920 x 1440, 1600 x 1200, 1680 x 1056, 1920 x 1080, 1440 x 912, 1376 x 768, 1280 x 960, 1280 x 800, 1280 x 720, 1280 x 1024, 1024 x 768, 1024 x 576, 800 x 600, 800 x 480, 768 x 576, 720 x 576, 704 x 576, 720 x 480, 640 x 480, 640x 368, 384 x 288, 320 x 240, 320 x 192 |
| Compression Format |
H.264, MPEG-4, JPEG |
| Maximum Frame Rate |
H264: 20 fps (1920 x 1440)
MPEG-4: 16 fps (1920 x 1440)
JPEG: 12 fps (1920 x 1440) |
| Multi streaming Capability |
Dual streaming*1 |
| Number of Clients |
10 |
| Intelligent Video/Audio Analytics |
| Analytics Architecture |
DEPA Advanced |
| Intelligent Motion Detection |
Yes |
| Audio |
| Compression Format |
G.711/G.726 |
| System Requirements |
| Operating System |
Windows XP (32 bit) Professional Edition
Windows Vista (32 bit) Ultimate, Business Edition
Windows 7 (32/64 bit) Ultimate, Professional Edition |
| Processor |
Intel Core2 Duo 2.33 GHz or higher |
| Memory |
2 GB or more |
| Web Browser |
Microsoft Internet Explorer Ver. 6.0, Ver. 7.0, Ver. 8.0
Firefox Ver. 3.5 (plug-in free viewer only)
Safari Ver. 4.0 (plug-in free viewer only)
Google Chrome Ver.4.0 (plug-in free viewer only) |
| Network |
| Protocols |
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP(MIB-2) |
| Number of IP Address/Mac ADDRESS |
1 |
| ONVIF Conformance |
Profile S |
| Wireless Network |
No |
| Authentication |
IEEE 802.1X |
| Interface |
| Analog Video Output |
BNC (x1), 1.0 Vp-p, 75 Ω, unbalance, sync negative
600 TV lines (analog video) |
| Analog Monitor Output for Setup |
Phono jack (x1) |
| Microphone Input |
Mini jack (monaural) |
| Line Input |
Mini jack (monaural) |
| Line Output |
Mini jack (monaural), Maximum output level: 1 Vrms |
| Network Port |
10BASE-T/100BASE-TX (RJ-45) |
| Alarm Input (Sensor Input) |
x1, make contact, break contact |
| Alarm Output |
x2, 24 V AC/DC, 1 A |
| USB Slots |
No |
| General |
| Power Requirements |
IEEE 802.3af compliant (PoE) Class 0, DC 12 V, AC 24 V |
| Power Consumption |
29 W max. |
| Operating Temperature |
-30℃ to +50℃ (at AC 24 V or DC 12 V)
-22°F to +122°F (at AC 24 V or DC 12 V) |
| Cold Start Temperature |
-20 ℃ to +50℃ (at AC 24 V or DC 12 V)
-4°F to +122°F (at AC 24 V or DC 12 V) |
| Storage Temperature |
-20℃ to +60℃
-4°F to +140°F |
| Operating Humidity |
20% to 80% |
| Storage Humidity |
20% to 95% |
| Dimensions (W x H x D)*2 |
φ166 x 119 mm
φ6 5/8 x 4 3/4 inches |
| Mass |
Approx. 1380 g
Approx. 3 lb 0.68 oz |
