| Image Sensor |
1/4-type Super HAD II CCD |
| Image Sensor (Number of Effective Pixels) |
Approx. 570,000 pixels |
| Horizontal Resolution |
670TVL |
| Signal System |
PAL |
| Minimum Illumination (50%, Normal Mode) |
Color: 0.4 lx Typical (F1.4, AGC on, 1/50 s)
Color: 0.03 lx Typical ( F1.4, AGC on, 1/3 s)
ICR-ON : 0.01 lx (F1.4, AGC on, 1/3 s) |
| Recommended Illumination |
100 lx to 100,000 lx |
| S/N Ratio |
More than 50 dB |
| Gain |
Auto/Manual (-3 step to 28 step, +2 step/total 16 steps)
Max. Gain Limit (6 step to 28step, +2 step step/total 12 steps) |
| Shutter Speed |
1/1 s to 1/10,000 s, 22 steps |
| Sync System |
Internal/External(V-Lock) |
| Exposure Control |
Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow AE |
| Backlight Compensation |
Yes |
| Aperture Control |
16 steps |
| White Balance |
Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto), One-push, Manual |
| Lens |
18x optical zoom
f=4.1mm (wide) to 73.8mm (tele)
F1.4 to F3.0 |
| Digital Zoom |
12x (216x with optical zoom) |
| Focusing System |
Auto (Sensitivity: normal, low), One-push AF, Manual, Interval AF, Zoom Trigger AF, Focus compensation in ICR on |
| Horizontal Viewing Angle (SD) |
48.0°(wide end) to 2.8°(tele end) |
| Minimum Object Distance |
10 mm (wide end) to 800 mm (tele end) (Default: 290 mm) |
| Auto ICR |
Yes |
| Wide-D *1 |
Yes (On/Off) (On : 90dB) |
| Noise Reduction |
Yes |
| Progressive Scan Mode |
Yes |
| Image Stabilization |
No |
| Stablezoom |
No |
| Digital Output |
Yes |
| Tone Reproduction |
Yes(VE) |
| Spherical Privacy Zone Masking |
Yes |
| Motion Detection |
Yes |
| Alarm |
Yes |
| Slow AE Response |
Yes (Approx. 2 minutes) |
| Picture Effects |
E-Flip, Nega Art, Black & White, Mirror image, Color enhancement |
| Picture Freeze |
Yes |
| Slow Shutter |
Yes |
| Temperature Readout |
Yes |
| Title Display |
20 characters/line, max. 11 lines |
| Camera Mode Display |
Yes |
| Key Switch Control |
Yes |
| Camera Operation Switch |
Yes |
| Video Output (SD) |
Analog: VBS Y/C
Digital: Y/Cb/Cr 4:2:2 (ITU-R BT656 Style) |
| Camera Control Interface |
VISCA (CMOS 5 V level)
Baud rate: 9.6 Kbps, 19.2 Kbps, 38.4 Kbps Stop bit: 1 bit |
| Power Requirements |
6.0 V to 12.0 V DC |
| Power Consumption |
2.4W(zoom/focus inactive, 9V)
3.2W(zoom/focus active, 9V) |
| Operating Temperature |
-5 ℃ to +60 ℃
23°F to 140°F |
| Storage Temperature |
-20 ℃ to +60 ℃
-4°F to 140 °F |
| Operating Humidity |
20% to 80% |
| Storage Humidity |
20% to 95%
Absolute humidity : 36 [g/m3] |
| Dimensions (W x H x D) *2 |
52.7 x 57.5 x 88.5 mm
2 1/8 x 2 3/8 x 3 1/2 inches |
| Mass |
Approx. 225 g
Approx. 7.9 oz |
