| Image Sensor |
1/4-type EXview HAD CCD |
| Image Sensor (Number of Effective Pixels) |
Approx. 440,000 pixels |
| Signal System |
PAL |
| Minimum Illumination (50%, Normal Mode) |
1.4 lx (F1.6, ICR off, 1/60 s)
0.1 lx (F1.6, ICR off, 1/4 s) |
| Recommended Illumination |
100 lx to 100,000 lx |
| S/N Ratio |
More than 50 dB |
| Gain |
Auto/Manual : -3 dB to +28 dB, +2 dB step |
| Shutter Speed |
1/1 to 1/10,000 s, 22 steps |
| Sync System |
Internal/External (V-lock) |
| Exposure Control |
Auto, Manual, Priority mode (shutter & iris priority), Bright, EV compensation, Slow AE |
| Backlight Compensation |
Yes |
| Aperture Control |
16 steps |
| White Balance |
Auto, ATW, Indoor, Outdoor, One-push, Manual |
| Lens |
F1.6 to F4.5
f=3.4 mm (wide) to 122.4 mm (tele)
36x optical zoom |
| Digital Zoom |
12x (432x with optical zoom) |
| Focusing System |
Interval AF, Zoom Trigger AF
Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity |
| Horizontal Viewing Angle (SD) |
57.8°(wide end) to 1.7°(tele end) |
| Minimum Object Distance |
300 mm (2ide end) to 1,500 mm (tele end) |
| Auto ICR |
Yes |
| Wide-D *[1] |
Yes |
| Noise Reduction |
No |
| Progressive Scan Mode |
No |
| Image Stabilization |
No |
| Stablezoom |
No |
| Digital Output |
No |
| Spherical Privacy Zone Masking |
Yes |
| Motion Detection |
Yes |
| Alarm |
Yes |
| Slow AE Response |
Yes (Up to 32 times) |
| Picture Effects |
E-Flip, Nega Art, Black & White, Mirror image |
| Picture Freeze |
Yes |
| Slow Shutter |
Yes |
| Temperature Readout |
No |
| Title Display |
20 charcters/line, max. 11 lines) |
| Camera Mode Display |
Yes |
| Key Switch Control |
Yes |
| Camera Operation Switch |
No |
| Video Output (SD) |
Analog: VBS (1.0 Vp-p), Y/C |
| Camera Control Interface |
VISCA (CMOS 5 V level)
Baud rate: 9.6 Kbps, 19.2 Kbps, or 38.4 Kbps, Stop bit: 1 bit |
| Power Requirements |
6.0 V to 12.0 V DC |
| Power Consumption |
4.9 W (motors active)
2.6 W (motors inactive) |
| Operating Temperature |
32°F to 122°F
0°C to 50°C |
| Storage Temperature |
-4°F to 140 °F
'-20°C to +60°C |
| Operating Humidity |
20% to 80% |
| Storage Humidity |
20% to 95% |
| Dimensions (W x H x D) *[2] |
50.0 x 57.5 x 87.9 mm
2 x 2 3/8 x 3 1/2 inches |
| Mass |
Approx. 8.1 oz
Approx. 230 g |
