| Camera |
| Image Sensor |
1/4 type Exmor CMOS |
| Number of Effective Pixels |
Approx. 1.43 Megapixels |
| Signal System |
NTSC color system / PAL color system (switchable) |
| Sync System |
Internal synchronization |
| Minimum Illumination (50 IRE) |
Color: 1.0 lx (F1.35, shutter 1/30 sec, AGC ON, 50 IRE)
B/W: 0.1 lx (F1.35, shutter 1/30 sec, AGC ON, Night Mode, 50 IRE) |
| Minimum Illumination (30 IRE) |
Color: 0.7 lx (F1.35, shutter 1/30 sec, AGC ON, 30 IRE)
B/W: 0.07 lx (F1.35, shutter 1/30 sec, AGC ON, Night Mode, 30 IRE) |
| Dynamic Range |
Theoretically 86 dB by DynaView Technology |
| S/N Ratio (Gain 0 dB) |
50 dB (Gain 0 dB) |
| Gain |
Auto/Manual (-3 to +28 dB) |
| Shutter Speed |
1/1 s to 1/10000 s |
| Exposure Control |
Full auto, Shutter priority, Iris priority, Manual |
| White Balance |
Auto, ATW, Indoor, Outdoor, One-push, Manual, Sodium vapour lamp |
| Lens |
Auto-focus zoom lens |
| Powered Zoom |
Yes |
| Easy Zoom |
No |
| Zoom Ratio |
Optical zoom 28x
Digital zoom 12x
Total zoom 336x |
| Powered Focus |
Yes |
| Horizontal Viewing Angle |
55.9° to 2.1° |
| Focal Length |
f = 3.5 mm to 98 mm |
| F-Number |
F1.35 to F3.7 |
| Minimum Object Distance |
10 mm (wide) to 1500 mm (tele) |
| Pan/Tilt/Rotation Angle (manual) |
340° / 105° |
| Pan Speed |
300°/s (max.) |
| Tilt Speed |
300°/s (max.) |
| Number of Preset Positions |
256 |
| Number of Tour Programs |
5 |
| IR Illuminator |
No |
| Camera Features |
| Day/Night |
True D/N |
| Wide-D |
DynaView |
| Tone Correction |
No |
| Noise Reduction |
NR |
| Image Stabilizer |
No |
| Vandal Resistant |
No |
| Ingress Protection |
No |
| Video |
| Resolution |
1280 x 720, 1024 x 576, 800 x 600, 800 x 480, 768 x 576, 720 x 576, 704 x 576, 720 x 480, 640 x 480, 640 x 368, 384 x 288, 320 x 240, 320 x 192 |
| Compression Format |
H.264, MPEG-4, JPEG |
| Maximum Frame Rate |
H.264/MPEG-4/JPEG : 30 fps (1280x720) |
| Multi streaming Capability |
Dual streaming*1 |
| Number of Clients |
5 |
| Intelligent Video/Audio Analytics |
| Analytics Architecture |
DEPA |
| Intelligent Motion Detection |
Yes |
| Audio |
| Compression Format |
G.711/G.726 |
| System Requirements |
| Operating System |
Windows XP (32 bit) Professional Edition
Windows Vista (32 bit) Ultimate, Business Edition
Windows 7 (32/64 bit) Ultimate, Professional Edition |
| Processor |
Intel Core2 Duo 2 GHz or higher |
| Memory |
1 GB or more |
| Web Browser |
Microsoft Internet Explorer Ver. 6.0, Ver. 7.0, Ver. 8.0
Firefox Ver. 3.5 (plug-in free viewer only)
Safari Ver. 4.0 (plug-in free viewer only)
Google Chrome Ver.4.0 (plug-in free viewer only) |
| Network |
| Protocols |
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP(MIB-2) |
| Number of IP Address/Mac ADDRESS |
1 |
| ONVIF Conformance |
Profile S |
| Wireless Network |
No |
| Authentication |
IEEE802.1X |
| Interface |
| Microphone Input |
Mini jack (monaural) |
| Line Output |
Mini jack (monaural), Max ouput level: 1 Vrms |
| Network Port |
10BASE-T/100BASE-TX (RJ-45) |
| Alarm Input (Sensor Input) |
x2 |
| Alarm Output |
x1 |
| Card Slots |
SD /SDHC card x1 |
| USB Slots |
No |
| General |
| Power Requirements |
IEEE 802.3at compliant (PoE+) Class 4, AC 24 V |
| Power Consumption |
Approx. 25 W |
| Operating Temperature |
-5℃ to +50℃
+23°F to +122°F |
| Cold Start Temperature |
0 ℃ to +50℃
+32°F to +122°F |
| Storage Temperature |
-20℃ to +60℃
-4°F to +140°F |
| Operating Humidity |
20% to 80% |
| Storage Humidity |
20% to 95% |
| Dimensions (W x H x D)*2 |
φ147.4 x 190.9 mm
φ5 7/8 x 7 5/8 inches |
| Mass |
Approx. 1.7 kg (including ceiling bracket)
Approx. 3 lb 12 oz (including ceiling bracket) |
