Detailed Product Description
| Image Device: |
1/ 2 Type IT CCD |
Effective Picture Elements: |
768 X 494 |
| Weight: |
110 G |
Minimum Illumination: |
0.1 Lx |
| Size: |
29 X 29 X 32 Mm |
Weight: |
50G |
| Horizontal Resolution: |
570 TV Line |
|
|
Analog Near Infrared Industrial Camera Systems XC-EI50 B/W EIA
XC-EI50 Feature:
* High sensitivity using the 1/2" CCD with HAD technology
* All controls outside the camera
* Simplified and flexible trigger
* Smallest and lightest, one piece analog B/W video camera offered by Sony
* Excellent vibration and shock characteristics (10G / 70G)
* Small and light weight power adaptor (DC-700/700CE)
SONY XC-EI50:
Ideal for image processing and machine vision applications and weighing only 60 grams, Sony's XC-EI50 video camera is the smallest and lightest one-piece 1/2-inch analog B/W video camera in Sony's lineup to date. This camera features the same CCD technology and improved specifications that are incorporated in the XC-ST70/50/30 series (e.g., simplified and flexible trigger, excellent vibration and shock characteristics) but in an even smaller and lighter package. In order to achieve this extremely small size, the BNC connector has been removed from the XC-EI50 camera. This camera incorporates the latest 1/2 type Interline Transfer (IT) CCD with HAD technology providing 768(H) x 494 (V) effective picture elements and features a C-mount type lens mount. When used with an IR LED illuminator, this camera can capture images in very low light environments and/or easily detect features that are more distinguishable in IR illumination
Specificatoin:
| Camera Specifications |
Detail: |
| Image Device |
1/ 2 type IT CCD |
| Image Device Value |
Monochrome |
| Cell Size |
8.4 x 9.8 μm |
| Effective Pixels |
768 x 494 |
| Camera Interface |
Analog |
| Lens Mount |
C-mount |
| Horizontal Frequency |
15.734 kHz |
| Flange Back |
17.526 mm |
| Vertical Frequency |
59.94 Hz |
| Resolution |
VGA |
| External Sync Frequency |
+/- 1% |
| Sync System |
Internal / External (auto) |
| External Sync Signal |
HD / VD (2 to 5 Vp-p)
VS |
| Jitter |
Less than +/- 50 nsec |
| Scanning System |
2:1 Interlaced |
| Gain |
AGC (0-18 dB)
Manual (0-18 dB) Selectable |
| Gamma |
ON / OFF |
| Normal Shutter |
1/ 100 to 1/ 10000 s |
| External Trigger Shutter / Speed |
1/ 4 to 1/ 10000 s |
| Video Output Specifications |
Detail: |
| Horizontal Resolution |
570 TV lines |
| Minimum Illumination |
0.1 lx |
| S/N Ratio |
60 dB |
| Sensitivity |
400 lx F11
(γ = ON MIN GAIN
NO IR cut filter) |
| Signal System |
EIA (standard) |
| Video Output |
1.0 Vp-p
Negative
75 Ω
Unbalanced |
| General Specifications |
Detail: |
| Dimensions (W x H x D) |
1 3/16 x 1 3/16 x 1 5/16 inches
(29 x 29 x 32 mm) |
| Weight |
50 g (2 oz) |
| Power Requirements |
DC12 V (+9 to 16 V) |
| Power Consumption |
1.6 W |
| Operating Temperature |
-10 to +50°C (14 to +122°F) / 20 to 80% |
| Storage Temperature |
-20 to +60°C (-4 to +140°F) / 20 to 95% |
| Operating Humidity |
20 to 80 % (no condensation) |
| Storage Humidity |
20 to 95 % (no condensation) |
| Vibration Resistance |
10 G (20 to 200 Hz) |
| Shock Resistance |
70 G |
| Regulatory Compliance |
UL1492
FCC Class A Digital Device
CE (EN50081-2 + EN50082-2)
AS4251.1 + AS4252.2 |
